Specifications

• • Platform Width……………………….36”
  • Platform Length……………………..80”/ 84” / 88”
  • Minimum Height……………………..8”
  • Maximum Height…………………….32”
  • Capacity……………………………….600 lbs.
  • Backrest Angle……………………….͂ 65°
  • Footrest Angle……………………….͂ 34°
  • Trendelenburg Position……………͂ 12°

Description

• • Extremely reliable, mobile and flexible, the Versatech was designed to ensure the utmost in safety for both patients and medical staff. With its ability to be lowered to 8 in. from the floor, a 600 lb. total load capacity and a broad range of features, the Versatech bed is nothing short of brilliantly designed.

Features

• • • Can be lowered to 8 in. from the floor, thus minimizing the risk of falls and simplifying the application of restraint protocols.
    • Sturdy and reliable, with a load capacity of 600 lbs. (Also available with a load capacity of 1100 lb.
    • Fixed frame provides greater stability, thus eliminating back-and-forth movements of the wheelbase.
    • Ball bearing mechanisms ensure smooth transitions and effortless maneuverability in every position.
    • A set of 5 in. double casters provide superior ease of maneuverability.
    • Integrated expandable frame, allows mattress deck to be extended without using any tools from 80 in. to 84 in. to 88 in.
    • A patent pending lift system enables heavy loads to be lifted from a very low height.
    • A four-caster central braking system allows bed height adjustments even when the casters are looked.
    • Elevated side rails equipped with ergonomic handles provide additional safety even when using thicker care mattresses.
    • Frame integrated receptacle for the trapeze bar.
    • Integrated scale option does not affect the 8 in. low-profile feature.
    • Unique design provides a clearance of 6 in. x 42 in.(low-profile bed), thereby allowing wheeled equipment to be positioned underneath the bed.
